| Product Name | Suction Diffuser |  |
|---|---|---|
| Patt.No | ISD01 | |
| Working Pressure | 16bar | |
| Working Temperature | -10°C~120°C | |
| Flange Types | EN1092-2 PN10/PN16/PN25 ANSI B16.1 Class 125 JIS10K/16K |
| Product Name | Suction Diffuser | |
|---|---|---|
| Patt.No | ISD01 | |
| Working Pressure | 16bar | |
| Working Temperature | -10°C~120°C | |
| Flange Types | EN1092-2 PN10/PN16/PN25 ANSI B16.1 Class 125 JIS10K/16K |
